The fluorocarbon spraying process flow is: Pretreatment process: degreasing and decontamination of aluminum profiles →water washing→alkali washing (degreasing)→water washing→acid washing→water washing→chromization→water washing→pure water washing Spraying process: Primer spraying→topcoat→gloss coating→baking (180-250℃)→quality inspection The multi-layer spraying process consists of three sprays (referred to as three sprays), including primer, topcoat, and topcoat, as well as secondary sprays (primer, topcoat). 1. Purpose of pretreatment: Before spraying aluminum alloy profiles , the surface of the workpiece needs to undergo degreasing, decontamination, and chemical treatment to produce a chromized film, increase the adhesion and oxidation resistance between the coating and the metal surface, and is conducive to extending the service life of the paint film. 2. Primer coating: As a primer coating for sealing the substrate, its function is to improve the impermeability of the coating, enhance the protection of the substrate, stabilize the metal surface layer, strengthen the adhesion between the topcoat and the metal surface, and ensure the color uniformity of the topcoat coating. The thickness of the paint layer is generally 5-10 microns. 3. Top coat coating: The top coat coating is a key layer of the spray coating, which provides the decorative color required for the aluminum material, making the appearance of the aluminum material meet the design requirements, and protecting the metal surface from external environmental atmosphere, acid rain, pollution, and UV penetration. The anti-aging ability is greatly enhanced. The top coat is the thicker one in spraying, and the thickness of the paint layer is generally 23-30 microns. 4. Glossy paint coating: Glossy paint coating, also known as varnish coating, mainly aims to more effectively enhance the paint layer's resistance to external corrosion, protect the topcoat coating, increase the metallic luster of the topcoat color, make the appearance more vivid and dazzling, and the coating thickness is generally 5-10 microns. The total thickness of the three spray layers is generally 40-60 microns, and can be thickened if special needs arise. 5. Curing treatment: the three spray coating generally needs secondary curing. The aluminum materials are treated in the curing furnace. The curing temperature is generally between 180℃-250℃, and the curing time is 15-25 minutes. Different Fluorocarbon manufacturers will provide better temperature and time according to their own coatings. Fluorocarbon spraying plants (curium oil plants) also have their own experience in changing the two curing times during the three spraying to one curing. 6. Quality inspection: Quality inspection should follow the AAMA-605.02.90 standard. Strict quality inspection is essential to ensure high-quality spraying products.
Read More
Aluminum profiles are aluminum materials with different cross-sectional shapes obtained by hot melting and extrusion of aluminum rods. The production process of aluminum profiles mainly includes three processes: casting, extrusion, and coloring. Among them, coloring mainly includes processes such as oxidation, electrophoretic coating, fluorocarbon spraying, powder spraying, and wood grain transfer printing. Classification method for aluminum profiles 1、 It can be divided into the following categories according to its purpose: 1. Architectural aluminum profiles (divided into two types: doors, windows, and curtain walls) 2. Radiator aluminum profiles. 3. General industrial aluminum profiles: mainly used for industrial production and manufacturing, such as automated mechanical equipment, the framework of covers, and customized mold opening according to the requirements of various companies' mechanical equipment, such as assembly line conveyor belts, elevators, dispensing machines, testing equipment, shelves, etc., are mostly used in the electrical machinery industry and clean rooms. 4. Aluminum alloy profiles for railway vehicle structures: mainly used in the manufacturing of railway vehicle bodies. 5. Frame aluminum profiles, create aluminum alloy picture frames, and frame various exhibitions and decorative paintings. 2、 Classification by alloy composition Aluminum profiles can be classified into alloy grades such as 1024, 2011, 6063, 6061, 6082, and 7075, with the most common being the 6 series. The difference between different grades lies in the different proportions of various metal components. Except for commonly used building aluminum profiles such as 60 series, 70 series, 80 series, 90 series, curtain wall series, etc. for doors and windows, there is no clear model distinction for industrial aluminum profiles. Most production factories process them according to the actual drawings of customers. 3、 Typical uses of different grades of aluminum alloys 1050: Extruded coils, various hoses, fireworks powder for food, chemical, and brewing industries 5050: Thin plates can be used as inner lining plates for refrigerators and refrigerators, as well as for automotive air pipes, oil pipes, and agricultural irrigation pipes; It can also process thick plates, pipes, bars, irregular materials, and wires, etc 5154: Welded structures, storage tanks, pressure vessels, ship structures and offshore facilities, transport tanks 6010: Sheet: Automotive Body 6061: Various industrial structures with certain strength, weldability, and high corrosion resistance are required, such as pipes, rods, shapes, and plates for manufacturing trucks, tower buildings, ships, electric vehicles, furniture, mechanical parts, precision machining, etc 6063: Industrial profiles, building profiles, irrigation pipes, and extruded materials for vehicles, racks, furniture, fences, etc 6066: Forgings and welded structural extrusion materials
Read More
On the morning of April 29th, the "Integration of Industry and City · Walking with 'Carp'" - the 2023 Leshan Hiking and Golden Carp Colorful Carnival in Shishan Town to welcome the May Day holiday was held at Boai Lake Park. As one of the important supporting units for this event, Knowledge City Guang Ya Holding Group actively responded to the call and organized a team of 50 employees to participate in the event, with a total of over 5000 people from 122 other units. Together, they measured the development achievements of Shishan Town and felt the charm of Shishan Town in Foshan City. At 8 a.m that day, 50 people from Guang Ya, a knowledge group, dressed in unified white corporate culture shirts and waving red company flags, excitedly shouted the slogan "Guang Ya Aluminum Industry Accompanying With You", and appeared at the starting point of hiking in full mental state, waiting for the start of the challenge. Accompanied by the resounding sound of the whistle, the hiking activity officially started, and a highly anticipated 8000 meters hiking trip was officially launched. The Knowledge City Guang Ya Hiking team can feel the gentle breeze blowing from Boai Lake. People sometimes chat and laugh, sometimes encourage each other, and sometimes stop to take photos. While enjoying the beautiful scenery along the way, everyone stays together and radiates new vitality! During the hiking activity, it suddenly rained cats and dogs, but it did not affect the determination of the Knowledge City team to move forward. In the end, all members of the Guang Ya team in the Knowledge City completed eight kilometers' hiking check-in, showcasing the spirit of the manufacturing industry in Nanhai District, Foshan City, and inheriting the spirit of the "Huangpu Iron Army". They worked hard and bravely climbed to the peak. Through this hiking activity, the employees exercised their bodies, relaxed their mood and released their pressure. At the same time, this hiking activity also strengthened the company's cohesion and centripetal force, leading everyone to prepare to start again and better engage in work.
Read More
From August 10 to 12, the 2022 South China International Aluminum Industry Exhibition was grandly held in hall 6-7 of Guangdong Tanzhou International Convention and Exhibition Center. Based on Foshan, the core city of the "Guangdong, Hong Kong and Macao" bay area, this exhibition focuses on the market frontier trend, deeply insight into the industry demand, and fully display the new products, new technologies, new processes and new applications of the whole industrial chain of the aluminum industry, including aluminum and aluminum alloys, aluminum processing materials, aluminum components, finished products, related mechanical equipment, auxiliary materials and consumables. As a well-known brand in the aluminum industry, Guang Ya aluminum made a brilliant appearance with its innovative application achievements in the aluminum industry. The related products displayed covered the application fields of photovoltaic new energy, automobile lightweight, 3C electronics, 5g communication, mechanical equipment, rail transit, aerospace and so on. It comprehensively presented the new mission and new action of the enterprise to respond to the "double carbon" （peaking carbon dioxide emissions and achieving carbon neutrality）goal with innovative technology and help the green and efficient development of the industry, and highlighted the new mission and new action of having a foothold Greater Bay Area, radiating the whole country and the new pattern and new results of going global which coincide with the theme of the exhibition and complement each other. In booth J10 of hall 7 in zone B, the exhibition hall in the shape of a tree bridge, the porcelain white visual design, and the scattered product display show that Guang Ya aluminum presents a simple space feeling different from the traditional exhibition hall, which has received the keen attention of customers and mainstream media throughout the country and attracted many visitors to stop and inquire. Among them, industrial aluminum materials represented by automobile lightweight, photovoltaic profile products and electronic communications have become the focus of the booth, with more attention than in previous years. Based on the current situation of the industry, with the decline of the real estate market demand and the implementation and promotion of the "double carbon" policy, the domestic aluminum consumption structure is undergoing profound changes. The new energy automobile, the photovoltaic and 5g industries are developing rapidly. In particular, there has been an "explosive" increase in 2021, which directly promotes the relevant industries from "policy driven" to "market driven" and enters the fast lane of the industry. Guang Ya aluminum is looking forward to laying out a high growth track, vigorously developing industrial materials, introducing the latest technology and cooperation through the combination of industry through university and research, accelerating the implementation of new produc...
Read MoreGood news is spreading and inspiring people, and we will work together to open a new situation. Recently, Guangya Aluminum Co., Ltd. has received good news one after another. It not only won the "2024 Shishan Town Economic Development Outstanding Contribution Enterprise (Silver Award)", but also won the "China Nonferrous Metals Industry Science and Technology Award Second Prize" for participating in the formulation of the first ISO international technical standard for the aluminum processing industry, "Organic Coatings for Aluminum and Aluminum Alloys-Specifications for Organic Coatings for Aluminum Surface Decoration and Protection-Part 2 Liquid Coatings". The acquisition of the two honors marks that Guangya Aluminum has achieved a double breakthrough in the fields of regional economic leadership and global technical standard formulation. 01 2024 Shishan Town Economic Development Outstanding Contribution Enterprise (Silver Award) On February 26, at the 2025 Shishan Town Entrepreneurs Conference, Guangya Aluminum Co., Ltd. won the "2024 Shishan Town Economic Development Outstanding Contribution Enterprise (Silver Award)" for its continued outstanding contribution to the regional economy. Long Wen, Chairman of Guangya Group, was invited to attend the conference and took the stage to accept the award. This honor is not only a high recognition of the company's comprehensive strength, but also highlights Guangya Aluminum's demonstration and leading role in stabilizing growth, promoting transformation, and strengthening the industrial chain. As a leading enterprise in the aluminum profile industry, Guangya Aluminum has actively fulfilled its social responsibilities while continuously promoting transformation and upgrading and high-quality development goals, and has injected strong impetus into local economic development in terms of tax contribution, employment promotion, and industrial collaborative innovation. In the nearly 30 years of development, Guangya Aluminum has closely focused on the concepts of innovation, green, and development, and has been deeply involved in the field of aluminum profiles. On the one hand, we invest in technology research and development, continue to make efforts in product design, process improvement, etc., improve product quality and performance, promote the extension of the aluminum industry chain to terminal products and high-end products, enhance market competitiveness, and actively expand the application field of aluminum materials in industrial materials to achieve kinetic energy conversion; on the other hand, we continue to optimize energy utilization and resource management in the production process to achieve green and sustainable development. In addition, through in-depth market research, we accurately grasp customer needs, continuously optimize product structure and service system, expand sales channels, enhance brand influence, and accumulate a good market reputation. 02 Sec...
Read More
Aluminum profiles are aluminum materials with different cross-sectional shapes obtained by hot melting and extrusion of aluminum rods. The production process of aluminum profiles mainly includes three processes: casting, extrusion, and coloring (coloring mainly includes oxidation, electrophoretic coating, fluorocarbon spraying, powder spraying, etc.). Aluminum materials are extremely unstable in the air and can easily form oxide films that are difficult to recognize with the naked eye. Due to the different processing methods for aluminum parts, such as casting, direct cutting from extruded sheets, mechanical precision processing, or heat treatment or welding after different processes, the surface of the workpiece will present different states and varying degrees of dirt or marks. Therefore, in the pre-treatment process, the pre-treatment process must be selected based on the actual situation of the workpiece surface. In the pretreatment process, attention should be paid to: although the natural oxide film on the surface of the fine machined parts is only initially formed, the unmachined surface is left with an excessively thick oxide layer formed during the casting process, and a layer of oily sintered coke is formed before the workpiece is transferred to the heat treatment or welding process. The treatment precautions are as follows: (1) The problems to be noticed in the pretreatment process of fine machined parts: although the natural oxide film on the surface of fine machined parts has just formed and is easy to remove, it is greasy, especially in and around the eyelet (added due to lubrication needs during machining). Such parts must be cleaned with organic solvent first. If you directly use alkali, it is not only greasy and hard to remove, but also the fine machined surface can not withstand strong alkali corrosion for a long time, The result will also affect the roughness and tolerance fit of the workpiece surface, which may eventually become a waste product. (2) The issues that need to be noted in the pre-treatment process of casting molded parts. Not all surfaces of cast parts have undergone mechanical processing. Unmachined surfaces have an excessively thick oxide layer formed during the casting process, and some even contain sand layers. At this time, the original oxide film in this area should be removed first using machining or sandblasting methods, or processed after alkali washing. Only in this way can the original oxide layer in the unprocessed area be removed and the tolerance dimensions of the machined area be avoided from changing. (3) During the pre-treatment process of workpieces that have undergone heat treatment or welding, attention should be paid to the following issues: according to the process requirements, the workpieces need to be cleaned with organic solvents before being transferred to the heat treatment or welding process to remove surface oil stains. However, currently, this is generally not possible. Therefore, a ...
Read MoreOn December 3, the 2024 Guangdong Manufacturing Top 500 Enterprises Summit and the Guangxi Chongzuo Promotion Conference for East-West Cooperation between Guangdong and Guangxi, jointly sponsored by the Guangdong Manufacturing Association, Guangdong Development and Reform Research Institute, and Jinan University Industrial Economics Research Institute, was grandly held in Guangzhou. The "2024 Guangdong Manufacturing Top 500 Enterprises Research Report" was released at the conference. Knowledge City Guangya (Guangzhou) Holding Group Co., Ltd. ranked 49th among the top 500 enterprises in Guangdong Province with its huge production scale and profound industry influence. The Guangdong Top 500 Manufacturing Enterprises are the leaders of the province's manufacturing industry above a certain scale, driving the development of various industries and industrial chains in the manufacturing industry, and are the main force for the stabilization and sustainable development of the province's manufacturing industry and even the regional economy. Knowledge City Guangya Group was listed in the list and ranked in the top 50, which is not only a full affirmation of the comprehensive strength and development potential of Knowledge City Guangya Group, but also a high recognition of its promotion of industry progress and economic development. Knowledge City Guangya Group has always insisted on innovation-driven development and continuously improved its core competitiveness. In terms of technology research and development and quality assurance, Guangya Aluminum holds more than 500 patents and national certifications, has a national research and development center, a testing center, and is equipped with a complete quality management system. In terms of production scale and product coverage, Guangya Aluminum has three major production bases, and its cooperation cases cover more than 30 provinces and cities across the country and more than 70 countries and regions around the world. Its products cover aluminum door and window profiles, photovoltaic curtain walls, aluminum climbing frames, all-aluminum furniture, photovoltaic solar energy, etc., and it has strong production strength. Looking to the future, Knowledge City Guangya Group will take this honor as a new starting point and new driving force, adhere to the leadership of the Party, strengthen Party building, give full play to the advantages of state-owned enterprises, continue to deepen internal reforms, promote innovative transformation and development, and contribute to the high-quality development of Guangdong Province's manufacturing industry.
Read MoreGood news Guangya Aluminum Co., Ltd. On March 10, the 31st National Aluminum Door, Window and Curtain Wall Industry Annual Conference was grandly held in Guangzhou. The industry data statistics results were announced at the meeting. Guangya Aluminum once again won the title of "Top Ten Preferred Brands of Building Profiles" with its excellent product quality and high-quality service system. At the 2025 Aluminum Door, Window and Curtain Wall New Product Expo held at the same time, the highly anticipated "AL-Survey Preferred Innovative Material Brand Entry Certificate" award ceremony kicked off. Guangya Aluminum successfully entered the "2024-2025 Real Estate and Door, Window and Curtain Wall Industry Chain AL-Survey Preferred Innovative Materials TOP10". As the first brand launch platform for the domestic door, window and curtain wall industry, AL-Survey is provided with data statistical support by the Aluminum Door, Window and Curtain Wall Branch of the China Building Metal Structure Association and hosted by China Curtain Wall Network. Over the years, many powerful brands and rising stars in the door, window and curtain wall industry have been listed. The shortlisted companies are all leaders in their respective fields. They all have outstanding performance and project cases, and have become the support of the top domestic brands. It is understood that the "Preferred Brand" list has gradually become an important reference for readers such as real estate developers, general contractors, design institutes, door, window and curtain wall construction units, as well as industry experts, consulting companies, etc. to make brand choices and product purchases.
Read More
Energy is the material basis for the survival of life. It is a major problem faced by mankind in the 21st century. Green energy such as wind power, moderate-scale hydraulic power, bioenergy, solar energy, geothermal energy, etc. are increasingly valued by people. Among them, solar energy is the most potential and inexhaustible clean energy. With the development of the photovoltaic industry, its brackets have been transformed from steel products to aluminum alloy profiles, highlighting its environmentally friendly advantages such as lightness, durability, diversified structures, and recyclability. To this end, a reasonable product structure is designed through mechanical analysis, which can not only meet the usage requirements, but also have a simple and lightweight structure. 1.2 Design requirements: (1) Solar panel specifications: 1650mm×990mm×50mm (2) Number of solar panels installed: 14 ( 3) Solar panel array: 2×7=14 (4) Bracket tilt angle: 30° (5) Maximum wind speed: 42m/s (6) Snow load: 0.65kN/m2 (7) Solar panel load: 0.2kN/m2 (8) Installation conditions: Ground, ground roughness category II (9) Calculation standard: JIS C8955: 2011 (10) Product design life: 20 years 2 Strength design 2.1 Design conditions ①The snow load is 0.65kN/m2, and the maximum wind speed is set to: 42m/s. Seismic loads are not considered. It can be calculated that the vertical snow thickness is less than 1m, which is a calculation for ordinary places. ② According to the above, it can be assumed to be the maximum load in a general place, and the short-term composite load of the fixed load G and the wind pressure load W generated by the storm is used, that is, G+W; the load combination of G+S when there is snow. ③ Calculate the bending strength and bending amount of the material caused by the wind pressure blowing from the front of the bracket (downwind) and the wind pressure blowing from behind the bracket (headwind), and confirm the strength. ④ Maximum height H=2.175m. 2.2 Assumed loads ①Fixed load solar module: Gm =0.2kN/m2; Weight of T-shaped track 110: G2= 1.703×9.8/(1.65/2)=0.021kN/m2; Fixed load weight of single T-shaped track 110 G= 0.2+0.021=0.221kN/m2; ②Wind pressure load: Assume that the wind pressure load of the wind blowing from the front of the array (downwind) is Wp Wp=Cw×(0.6×V0 2 ×E×I) Cw—wind coefficient. This scheme is positive pressure. The calculation formula is: 0.65+0.009θ=0.65+0.009×30=0.92 V0—Wind speed 42m/s E—Environmental coefficient, since H=2.175m is less than Zb=5m According to formula (4), the ground roughness category is II Er=1.7×(Zb /ZG)α =1.7×（5/350）0.15=0.8988 E=Er 2 /m2 The wind pressure load of the wind (headwind) blowing from behind the array is Wp, and the wind coefficient is changed to: Cw—wind coefficient. This plan is negative pressure. The calculation formula is: 0.71+0.016θ=0.71+0...
Read More
